Product Features
-
Non pressure pvc pipes are mostly used for drainage and irrigation and sewage applications.
-
Samson PVC non pressure pipes are produced using virgin material to highest quality standards
-
Samson PVC non-pressure pipes provide long-term performance, toughness & durability for an extended system life.
-
These non-pressure pipes are a low-cost solution for a variety of plumbing applications.
Non Pressure Pipe
| Nominal Diameter | Mean OD | (Out of roundness) Ovality | For socketed pipes | Wall thickness of pipes (e) | |||||||||||||||||||||
| Solvent cement sockets and spigots | Solvent cement sockets and spigots | Wall thickness of sockets | |||||||||||||||||||||||
| Socket | Spigot | Socket | Spigot | SN2 | SN4 | SN8 | SN2 | SN4 | SN8 | ||||||||||||||||
| Mean inside diameter of a socket | Length of a solvent cement socket | length of Spigot | Length of Chamfer | Mean inside diameter of a socket | Length of engagement | depth of sealing zone | Length of spigot | Length of Chamfer | SDR 51 | SDR 41 | SDR 34 | SDR 51 | SDR 41 | SDR 34 | |||||||||||
| Socket e2 | Groove e3 | Socket e2 | Groove e3 | Socket e2 | Groove e3 | e | Mean em | e | Mean em | e | Mean em | ||||||||||||||
| Min | Max | Min | Max | Min | Max | Min | Max | Min | Max | Min | Max | Min | Max | Min | Max | Min | Max | Min | Max | Min | Max | ||||
| 20 | No data | No data | No data | No data | No data | No data | No data | No data | No data | No data | No data | No data | No data | No data | No data | No data | No data | No data | No data | No data | No data | No data | No data | No data | No data |
| 32 | 32.0 | 32.2 | 32 +- 0.77 | No data | 32.4 | 22 | No data | No data | 32.3 | No data | No data | No data | No data | No data | No data | No data | No data | No data | No data | No data | No data | No data | No data | 3.0 | 3.5 |
| 50 | 50.0 | 50.2 | 50 +- 1.2 | No data | 50.4 | 30 | No data | No data | 50.3 | No data | No data | No data | No data | No data | No data | No data | No data | No data | No data | No data | No data | No data | No data | 3.0 | 3.5 |
| 63 | 63.0 | 63.2 | 63 +- 1.51 | No data | 63.4 | 36 | - | - | 63.3 | No data | No data | No data | No data | No data | No data | No data | No data | No data | No data | No data | No data | No data | No data | 3.0 | 3.5 |
| 110 | 110.0 | 110.3 | 110+ - 2.64 | 110.2 | 110.6 | 48 | 54 | 6 | 110.4 | 32 | 26 | 60 | 6 | - | - | 2.9 | 2.4 | 2.9 | 2.4 | - | - | 3.2 | 3.8 | 3.2 | 3.8 |
